MN 12L CT Relay

Get a Price/Quote

MOQ : 10 Pieces

MN 12L CT Relay Specification

Contact Resistance
< 50 m

Contact Material
Silver Alloy

Coil Voltage
230V AC

Ambient Temperature
-10C to +55C

Contact Form
1 Change Over (SPDT)

Working Temperature
-10C to +55C

Protect Feature
Over Current, Under Current Protection

Dielectiric Strength
2kV AC for 1 Minute

Mechanical Life
> 10 Million operations

Coil Power
1.5 VA

Power Consumption
< 2 VA

Product Type
Current Monitoring Relay

Insulation Resistance
> 100 M at 500V DC

Theory
Electromagnetic Relay

Usage
Current Monitoring Relay

Contact Load
5A at 250V AC

Operate Time
< 200 ms

Terminal Type
Screw Terminal

Rated Voltage
230V AC

Supply Terminal
Din Rail Mount

Size
Standard

Color
Grey

Dimension (L*W*H)
22.5 mm x 80 mm x 100 mm

Weight
160 g

Indicator
LED Status Indicator

Frequency
50/60 Hz

Series
MN-12L CT

Mounting Type
35 mm Din Rail Mountable

Reset Time
< 150 ms

About MN 12L CT Relay

The MN 12L CT Relay is a hot-selling and featured current monitoring solution, acclaimed for its masterful design and first-class build quality. Engineered for reliability, it integrates splendid over-current and under-current protection with a rapid reset time of less than 150 ms and a robust LED status indicator. This electromagnetic relay fits a standard 35 mm DIN rail, operates on a rated voltage of 230V AC, and ensures longevity with a mechanical life exceeding 10 million operations, making it ideal for industrial and plant monitoring applications.

Versatile Applications and General Use

The MN 12L CT Relay stands out for its versatility, supporting both general and specific current monitoring needs. It is expertly suited for plant applications, control panels, and diverse industrial setups demanding over-current and under-current protection. With reliable operation in temperatures from -10C to +55C, this relay ensures stable performance in rigorous environments, securing plant machinery and sensitive equipment across various application places, whether in factories, utilities, or process automation sites.

Sample Accessibility and Assurance of Quality

MN 12L CT Relay samples are available upon request, subject to a reasonable asking price that reflects its market value. The product is supplied with relevant certifications to assure quality and compliance, facilitating a smooth delivery process. Suppliers and traders in India benefit from a sample policy designed to allow customers to verify performance prior to purchase, underscoring the relay's distinction as a credible, first-class choice for industrial current monitoring solutions.

FAQ's of MN 12L CT Relay:

Q: How is the MN 12L CT Relay mounted during installation?

A: The relay is conveniently mounted using a 35 mm DIN rail, ensuring secure and straightforward installation in control panels and industrial environments.

Q: What type of current protection does the MN 12L CT Relay provide?

A: This relay offers both over-current and under-current protection, making it ideal for various critical monitoring applications in plants and industrial systems.

Q: Where can the MN 12L CT Relay be effectively used?

A: It can be effectively utilized in factories, process automation sites, control panels, and utility installations, wherever reliable current monitoring and protection are required.

Q: What certifications come with the MN 12L CT Relay samples?

A: The relay samples are supplied with relevant certifications, ensuring they meet industry standards for quality and safety.

Q: What are the key operational features of the MN 12L CT Relay?

A: Key features include a fast reset time below 150 ms, an LED status indicator for monitoring, a mechanical life of over 10 million operations, and high contact reliability.
